SPEAK OUR LANGUAGE

• CELL – Core Experience Learning Lab
• SDR – Scientist Data Record

ASK WHY

Great scientists question the world around them. We encourage our LabLearner students to do the same. In anticipation of this, we explain the importance of learning the concepts in the Ask Why section within the CELL. Our hope is that these explanations help students understand why science matters.

BRANCH OUT

Each Investigation introduces students to a different branch of science or STEM (Science, Technology, Engineering, Mathematics) career that utilizes the scientific concepts of the CELL. These real-world connections will help students see the relevance of what they are learning. STEM connections are also integrated into each Performance Assessment.

GET FOCUSED

The Focus Questions in each Investigation are designed to help teachers and students focus on the important concepts. By the end of the CELL, students should be able to answer the following questions:

Investigation 1:

• What is the relationship among voltage, current, and resistance? The change in current in a circuit is directly proportional to the change in voltage. As voltage in a circuit increases, current increases but the resistance to the flow of current remains constant. The relationship among voltage, current, and resistance is described by Ohm’s law V= IR.

Investigation 2:

• What is the relationship among voltage, current, and resistance? Resistance is the ratio between the voltage and the current in a circuit. As voltage changes, current changes in proportion to the voltage. However, resistance remains constant.

• How do the dimensions of a resistor affect current? Increasing the length of a resistor increases the amount of resistance and decreases current, while increasing the cross-sectional area decreases the amount of resistance and increases current.

Investigation 3:

• What is the relationship between electricity and magnetism? There is a direct relationship between electricity and magnetism.

• What factors affect the strength of an electromagnet? The strength of an electromagnet is affected by the number of turns of wire in the coil over a specific length. The strength of an electromagnet is also affected by the amount of current flowing through the wire.

Note: These are succinct responses to the Focus Questions and are placed here for easy reference. Fully developed responses to the Focus Questions can be found on each PostLab page.

Note: Some questions may be revisited as the CELL progresses. As students acquire additional knowledge, their responses should reflect this.

LEARN THE LabLearner LINGO

The following list includes Key Terms that are introduced within the Backgrounds of the CELL. These terms should be used, as appropriate, by teachers and students during everyday classroom discourse.

Note: Additional words may be bolded within the Background(s). These words are not Key Terms and are strictly emphasized for exposure at this time.

Investigation 1:

• Current: the amount of charge that passes a given point in a specified period of time, measured in amperes (amps, A). The direction designated for current flow is opposite from the direction of the flow of electrons in a circuit. In a closed circuit powered by a battery, the direction of current flow is from the positive terminal to the negative terminal of the battery.
• Electric potential: the potential energy per unit of positive charge. Measured in volts.
• Multimeter: an instrument used to measure current, voltage, and resistance.
• Ohm’s Law: the ratio of voltage to current is resistance and is represented by the equation R = V/I, where R = resistance, V = voltage, and I = current.
• Potential difference: the difference in electric potential between point A and point B. In a circuit, point A and point B represent the positive and negative terminals of a power source such as a battery. Also known as voltage. Measured in volts (V).
• Resistance: the decrease in the flow of electrons and current due to a change in the diameter or material of a wire. Resistance is measured in ohms (Ω).
• Resistor: any wire in a circuit which causes a decrease in the flow of current due to its diameter or material. An example would be the filament in a light bulb. Also any wire placed into a circuit specifically to maintain the flow of electrons and current at a specific level.

Investigation 2:

• There are no new Key Terms introduced in Investigation 2.

Investigation 3:

• Tesla (T): Unit of measure for the magnitude of a magnetic field.

BE PREPARED

An overview of the materials for each lab is placed here for easy reference. Specific teacher preparation for the labs is placed at the beginning of each Lab page.

EXTEND YOUR THINKING

The following information is included so that teachers have additional background knowledge pertaining to the concepts introduced in the CELL. Teachers may choose to use this information to enrich students during instruction by integrating it into individual Concept presentations.

Electricity was first identified as a property of amber by the ancient Greeks. The term electricity is derived from the Greek word for amber, elektron. The Greeks chose this term because rubbing an amber rod with a piece of cloth caused the rod to attract dust. This was called the “amber effect”, and is now recognized to be the form of electricity known as static electricity.

Despite its use in many different forms of matter, electricity itself is not composed of matter. Instead, physicists refer to electricity as an event. To understand this distinction, it is important to remember that matter is composed of charged particles. The simplest form of matter is the atom. The atom consists of a nucleus containing protons and neutrons which is surrounded by an electron cloud. Protons are positively charged particles, electrons are negatively charged particles, and neutrons are particles which carry no charge at all. When atoms are neutral they have a net charge of 0, as all uncharged atoms have equal numbers of protons and electrons. However, when an atom gains or loses electrons it develops a negative or positive charge, respectively. This makes the atom attractive to other atoms which bear an opposite charge; i.e., positively charged atoms are attracted to negatively charged atoms and vice versa.

This attraction provides the basis for electricity and resulted in the formulation of Coulomb’s Law in 1785 by Charles Augustin de Coulomb. Through experimentation with tiny charged balls, Coulomb was able to apply Newton’s Third Law of Motion and show that the balls not only were attracted to one another with equal but opposite forces but also carried opposite charges (Figure 1). The international, or SI, unit for charge is the coulomb (C).

Coulomb’s experiments led him to demonstrate mathematically that the forces which attracted the spheres to one another were proportional to the product of the charges on the spheres as well as inversely proportional to the square of the distance separating their centers. For example, Coulomb showed that doubling the charge on a single sphere resulted in a doubling of the force. Further, he discovered that if he doubled the charge on both spheres the force quadrupled. This led to the development of Coulomb’s Law, which is written mathematically as:

The proportionality constant, k, is equal to 9.0 ! 109 N-m2/C2. Coulomb’s work led to the determination that an electron has a charge of 1.60219 ! 10-19 C. To put the charge of a single electron in perspective, a charge of 1 C would exert a force of 9 billion N. Charges of this magnitude are not normally encountered.

In its normal state, an atom typically has a net charge of 0. However, losing electrons creates a positive charge because protons now outnumber the electrons. Similarly, if an atom gains an electron it develops a negative charge because the electrons now outnumber the protons. The willingness to accept or donate electrons is a property of matter. Some types of matter are more willing to accept or donate electrons than others. Unlike materials are more likely to undergo electron transfer when rubbed together than like materials. Thus, rubbing a balloon with a wool swatch is more likely to result in a transfer of electrons than rubbing two glass rods or two wool swatches together.

Greater surface area of materials means a greater likelihood that electron transfer will occur. The amount of contact between the two objects also plays a role in electron transfer. For example, scuffing the sole of one foot against a carpet one time before touching a metal doorknob is unlikely to result in a shock, but scuffing both feet across the same carpet over several meters is likely to result in a tangible discharge of electricity upon contact between a person’s fingers and the doorknob. Even the simple act of sliding across seat upholstery when exiting a car can generate significant electron transfer. This is why signs at gasoline pumps advise touching a metal surface before refueling to discharge any built-up electrons. Otherwise, a static discharge could ignite fumes released when gasoline flows from the pump into the vehicle’s tank.

What is the relationship between static electricity and the electricity which powers appliances, known as current electricity? Electricity is electrons in motion. In static electricity, the electrons are moving between materials. In current electricity, electrons are moving through materials. In other words, electrons flow in a path just as water flows through a pipe (Figure 2a).

The flow of electrons in one direction in a material generates an apparent flow of positive charge in the opposite direction of the flow of electrons (Figure 2b). In the late 1700s, electrons had not yet been discovered. Thus, assignment of charge was arbitrary. Benjamin Franklin proposed that objects with an excess of charge were positively charged, and objects that were deficient in charge were negatively charged. In reality, the objects that Franklin determined to be positively charged had lost electrons so were technically deficient in electrons rather than having an excess of charge. Similarly, objects termed negatively charged by Franklin did not have a deficiency of positive charge. Instead, they had an excess of electrons. However, by the time electrons were discovered and determined to be the factor that actually flowed in an electric current Franklin’s terminology was firmly entrenched. Thus, current is still frequently referred to as a flow of positive charge. It should be remembered, however, that this is an apparent flow of positive charge, and it is the electrons which are actually in motion. The atomic nuclei where the positive charges are located (in the form of protons) are stationery within the material.

Electricity flows through a circuit. A circuit is an uninterrupted path between the terminals of a power source. Figure 3 illustrates a very simple circuit consisting of a battery and a light bulb. In this circuit, the direction of current flow (apparent flow of positive charge) is designated in a clockwise direction from the positive terminal, through the base and filament of the bulb and then back to the negative terminal through the tip of the bulb. Electrons, however, flow in the counterclockwise direction from the negative terminal through the circuit and back to the positive terminal.

A battery is a source of chemical potential energy. The most popular batteries are alkaline batteries because they are long-lasting. Alkaline batteries consist of a steel can lined with a compressed mixture of manganese oxide, graphite and an electrolyte. The manganese mixture plus the steel can serve as the battery’s cathode, or negative terminal. Inside the manganese oxide is a center core of zinc powder in a potassium hydroxide liquid. This zinc core is the anode (positive terminal) and is separated from the manganese by a paper filter soaked in an electrolyte solution. A brass nail inserted into the zinc mixture from the top collects the current and creates the raised area on the positive end of the battery. Figure 4 shows the arrangement of the two chemicals within the battery.

The two chemicals each have a different electrical potential. Electrical potential is defined as the energy per unit charge. This potential difference (difference in potential energy) provides the impetus for current flow. As illustrated in Figure 3, the direction of current flow is designated from areas of high potential (positively charged regions) to areas of low potential (negatively charged regions), even though electrons flow from the negatively charged regions to the positively charged regions. Current will not flow in a circuit unless there is a difference in potential. Only differences in potential energy can be measured. In electricity, this potential difference is measured in volts (V). Energy is measured in Joules (J), so 1 V = 1J/C. The volt is named after Alessandro Volta, who developed the first electric battery. Potential difference is also known as voltage, and the two terms are used interchangeably. Voltage is measured using a voltmeter.

Voltage is additive. Alkaline batteries all are rated at 1.5 V, as the potential difference between zinc metal and manganese metal is 1.5 V. However, some forms of alkaline battery, such as a transistor battery, are rated at higher voltages. A transistor battery shares the same chemical make-up as the D cell battery shown in Figures 3 and 4. However, the transistor battery is actually a series of six batteries, or cells, with positive and negative terminals touching inside a single case (Figure 5). The potential difference across the cells is six times the individual potential differences of the cells, or 9 V.

The current that is generated by differences in potential in a battery or other electrical circuit can be measured. Current is determined quantitatively by measuring the net amount of charge that passes a given cross-section of wire in a specified period of time. Current is abbreviated with the letter “I” and is defined mathematically as:

where !Q equals the net amount of charge passing the specified cross-sectional area of the wire and !t equals the given time period. Current is measured in amperes (A or amp) and 1 A = 1 C/s, named after 19th century French physicist André Ampère, who determined the relationship between current and the magnetic field around a wire. Current may also be called amperage, and is measured using an ammeter.

The amount of current which flows through a circuit is dependent upon the potential difference in the circuit as well as the type of wire in the circuit. Current flows more easily through some metals than others. This is dependent upon the atomic structure of the atoms of the substances which make up the wire in the circuit. Some atoms, such as those of tungsten, are more reluctant to allow the passage of electrons than others such as copper and aluminum. This property is known as resistance. Resistance is a function of both the type of material that makes up the wire and the wire’s dimensions. Long wires provide greater resistance than short wires, while wires with large cross-sectional areas provide less resistance than those with small cross-sectional areas. An excellent example of a wire with a very high resistance is the filament in an incandescent (lamp) bulb. The filament is made of a very thin tungsten wire that is two meters or more in length. The wire is coiled and then coiled back on itself in order to fit into the light bulb. The tremendous resistance provided by this combination of great length and tiny crosssectional area generates a white-hot heat that provides the light produced by the bulb. As resistance increases, the amount of current for a given voltage decreases proportionally. This can be demonstrated mathematically as:

where V equals voltage, I equals current, and R = resistance. This relationship is known as Ohm’s Law, as it was determined by one of Ampère’s contemporaries, Georg Simon Ohm. Manipulation of this equation yields the definition of resistance as the ratio of voltage to current:

Resistance is measured in ohms, abbreviated by the Greek letter omega (“); 1 ” = 1V/A. It should be pointed out that not all materials and devices adhere to Ohm’s Law; it is specific to metals which conduct electricity. A conductor of electricity is a substance which has electrons which can move freely. Substances in which the atoms hold tightly to their electrons, thus preventing electron flow, are called insulators, or nonconductors. Some substances are intermediate in their abilities to conduct electricity. These are classified as semiconductors. For materials that adhere to Ohm’s Law, R is independent of the applied voltage, and is thus a constant ratio between voltage and current. Materials and devices which do not adhere to Ohm’s Law are referred to as nonohmic. Nonohmic devices include electromagnets, transistors, diodes, and vacuum tubes. R=V/I can be applied to nonohmic devices, but is not a constant as it is dependent upon the voltage applied to the device, as shown in Figures 6 a and b.

The concept that opposite charges attract one another in electricity bears a strong resemblance to the same concept in magnetism. However, until 1820, scientists were unable to demonstrate any attraction between isolated electric charges and magnets. In 1820, Hans Christian Oersted demonstrated that while placing a compass next to a stationary charge such as that generated by rubbing wool on glass did not affect the compass, placing it next to a wire carrying an electric current caused the needle to deflect. Oersted had discovered that current moving through a wire generates a magnetic field in concentric circular paths around the wire (Figure 7a). The direction can be determined easily by using the right-hand rule (Figure 7b): wrap the right hand around the wire with the thumb pointing in the same direction as the flow of current. The fingers will curve around the wire in the same direction as the magnetic field.

The same effect is seen if the wire is made into a circular loop. The current generates a magnetic field that flows through the loop (Figure 7c). Figure 7d shows the right-hand rule as it applies to a loop of wire. The direction of the magnetic field follows the direction of the fingers, so that in the diagram the direction of the magnetic field is toward the palm of the hand. Notice that as in Figure 7b the thumb points in the same direction as the current.

If wire is coiled into a series of evenly spaced loops called a solenoid and electrified, a magnetic field is generated around and through the coil. If a metal bar such as a nail is placed in the center of the coil, the magnetic field generated by the current flowing through the coil turns the metal bar into an electromagnet. The bar loses its magnetic ability if the current is disconnected. The magnitude of the magnetic field (B) generated by the solenoid is determined by the number of loops of wire in the coil, the length of the coil, the amount of current present in the circuit, and a proportionality constant known as the permeability of free space. Magnetic field can be calculated using the following equation:

Where:

• B = magnitude of the magnetic field in tesla (T)
• μ0 = 4# ! 10-7 T-m/A
• N = number of loops of wire in the coil
• L = length of the coil in meters (m)
• I = current in amperes (A)

The quantity N/L represents the number of loops per length of the coil, and can be represented by “n”. Thus, the equation can be rewritten as:

As the magnitude of the magnetic field of the coil increases, the strength of the electromagnet increases, so that its ability to attract and hold objects made of materials with magnetic properties also increases. B can be increased by increasing the number of loops in a coil of a given length, decreasing the length of the coil without changing the number of loops, increasing the current, or by some combination of these factors. However, if the number of loops and the length of the coil are both increased, the ratio of loops to length must be greater than the starting ratio or B will not increase.

This Core Experience Learning Lab is designed to introduce students to the relationship between voltage, current, and resistance in ohmic devices by first demonstrating that voltage and current are proportional. Students will then discover that this proportional relationship is due to the resistance provided by the ohmic device (a resistor), and that in a circuit with constant voltage current will change in proportion to the amount of resistance present in the circuit. Students will place resistors in series to explore how resistance increases as resistor length increases. Students will also place resistors in parallel to generate the effect of increasing the diameter (and thus cross-sectional area) and discover that increasing the cross-sectional area decreases the amount of resistance in a circuit. Manipulation of resistor dimension using series and parallel circuits will reinforce for students the concept that resistance determines the rate at which electrons can flow through a circuit. Finally, students will explore the connection between electricity and magnetism by creating an electromagnet and testing the effects of changing the number of loops as well as the amount of current. Students will then have an opportunity to apply the concepts they have learned by using their knowledge of resistance and magnetic field to design a series of electromagnets of varying strengths.
